Rim Nakamura Signature

material: butted | 4130 crmo tubing, double butted top and down tube
top tube length: 21 inch
head tube angle: 75 degrees
head tube length : 115mm
seat tube angle: 71 degrees
chainstay length: 12,9 inch
bottom bracket height: 11,6 inch
standover height: 8,25 inch

headtube: compatible with integrated headsets (45/45) | 115mm
bottom bracket: mid | CNC shaped
seattube: fits 1 inch (25,4mm) seat posts
dropouts: 14mm slots | 6mm | 4130 crmo | heat-treated
downtube gusset: yes
toptube gusset: no

tire clearance: for big tires
brake mounts: yes (not included)
gyro tab holes: yes


additional information:
integrated seat clamp
double butted top and down tube
tapered seat stays and ovalized chain stays
