ODYSSEY

Odyssey R15 Fork

Odyssey R15 Fork

Shipping calculated at checkout.
Color
Size
Option

SKU

SKU:21600536

Barcode (EAN) per variant
CHROME / 15MM / 20'': 630950923403
BLACK / 15MM / 20'': 630950918942
Weight per variant
CHROME / 15MM / 20'': 0.87 kg
BLACK / 15MM / 20'': 0.87 kg
material: 41 thermal heat treated Chromoly
offset: 15mm
dropouts: 3/8 inch slots | 4mm thick | shape for grind and peg clearance
bearing race: integrated
steerer tube diameter: 1 1/8 inch
steerer tube length: 170mm
tire clearance: fits large tires

compression bolt: 24x1,5mm | 7075-t6
compression bolt tool: 6mm allen key | 8mm allen key

additional information:
41-thermal lifetime warranty against bending and breaking
custom tapered | butted and specially formed legs for improved grind and guard clearance
butted 1pc steerer tube redesign greatly improves strength and headset fit with built-in race
