material: 100% Seamless Sanko 4130 Chromoly Tubing
top tube length:choose available TT length in the size menu above
head tube angle: 75,5 degrees
head tube length: 127mm
seat tube angle: 71 degrees
chainstay length: 12,75 inch slammed
bottom bracket height: 11,7 inch
standover height: 9 inch

head tube: compatible with integrated headsets (45/45)
bottom bracket: mid | internally and externally cnc machined
seat tube: fits 1 inch (25,4mm) seat posts
dropouts: 14mm slots
down tube gusset: yes
top tube gusset: yes

tire clearance: for big tires
brake mounts: yes (included)
gyro tab holes: yes (gyro tabs not included)

additional information:
oval Chainstays For Tire Clearance Up To 2.5”
full CNC seatstay bridge with a custom brass badge inlay
anti-Slip Interior Dropout Knurling
all-new matte Golden Graphite colorway was hand-picked by Nathan
