material: 4130 CrMo | Japanese Sanko Triple Butted
toptube length: select toptube size in the menu above
head tube angle: 74 degrees
head tube length: 4,7 inch
seat tube angle: 71 degrees
chainstay length: 14 inch (slammed)
bottom bracket height: 11,5 inch
standover height: 9,25 inch

headtube: compatible with integrated headsets (45/45)
bottom bracket: mid | externally machined
seattube: fits 1 inch (25,4mm) seat posts
dropouts: 10mm slots | 5 mm thick
downtube gusset: yes
toptube gusset: yes

tire clearance: for big tires
brake mounts: yes (welded)
gyro tab holes: no

additional information:
trails specific geometry
10mm dropout slots
brake cable through the seat tube system
