frame: 100% Chromoly, Disc, with Rack and Fender mounts (M/L/XL 700c Compatible)
top tube length: choose available TT length in the size menu above (S: 520mm actual | XS:19,7 inch 505mm effective 487mm actual
head tube angle: 70 degrees
seat tube angle: 74,5 degrees
chain stay length: 415mm
bottom bracket drop:54mm
stand over height: 717mm

forks: 100% Chromoly | One-piece machined Steerer Tube
bars: Fairdale Archer v3, Aluminum
stem: 60mm, Forged Aluminum
headset: FSA integrated | 45º/45º | 1 1/8 inch
grips: Fairdale Swan
bar ends: Fairdale

front hub: Sealed Bearings, 32-H, Alum. Shell, Disc Brake Mount, w/Allen Skewer Axle
rear hub: Sealed Bearings, 32-H, Alum. Shell, Disc Brake Mount, w/Allen Skewer Axle
front rim: 27.5"/650b, 32-Hole, Aluminum, Double Wall, Pinned Rim, Tubeless compatible
rear rim: 27.5"/650b, 32-Hole, Aluminum, Double Wall, Pinned Rim, Tubeless compatible
front tire: 27.5" x 1.65" Maxxis Overdrive
rear tire: 27.5" x 1.65" Maxxis Overdrive

cranks: FSA Vero Pro 1X NW (XS,S =165mm)
bb: FSA
sprocket: 42t, Narrow-Wide
chain: KMC X9
pedals: Odyssey Twisted | plastic
gearing: Sturmey Archer, 11-36T, 9-Speed Cassette

seat: Fairdale Logo Seat
seat post: Micro Adjust, 27.2mm
seat post clamp: Fairdale | 30mm

brake: Promax DSK-717 | Front and Rear
brake cable: *
brake lever: Promax XL-91
R. Shift Lever: SRAM Apex 1, 11-Speed (Rear)
*R. Shift Lever Alternate: Microshift Advent Trigger, 9-Speed
R. Derailleur: SRAM Apex 1, Long Cage, 11-Speed
*R. Derailleur Alternate: Microshift Advent, 9-Speed
Shift Cable: Fairdale

pegs: not included
