Chase Dehart signature

material: full butter blended tubing | Chromoly
top tube length : choose available TT size (in inch) in the size menu above
head tube angle: 75,5 degrees
head tube length : 117.48mm
seat tube angle: 70 degrees
chainstay length: 13,25 inch (slammed)
bottom bracket height: 11,7 inch
standover height: 8,75 inch

headtube: compatible with integrated headsets (45/45)
bottom bracket: mid
seattube: fits 1 inch seat posts | integrated seat clamp
dropouts: 14mm slots | 5 mm thick
downtube gusset: yes
toptube gusset: yes

tire clearance: fits large tires
brake mounts: no (brakeless)
gyro tab holes: no
