material: 100% 4130 Chromoly
top tube length: select available TT length in the size menu
head tube angle: 75,5 degrees
seat tube angle: 71 degrees
chainstay length: 13,2 - 13,65 inch
bottom bracket height: 11,625 inch
standover height: 9 inch

headtube: 5 inch | compatible with integrated headsets (45/45) | heat treated
bottom bracket: mid | heat treated
seattube: fits 1 inch seatposts | integrated seat clamp
dropouts: 14mm slots | 6,5mm thick | investment cast | integrated chain tensioners
downtube gusset: yes | external
toptube gusset: yes | internal

tire clearance: fits large tires
brake mounts: removable M8 brake mounts (not included)
gyro tab holes: yes

additional information:
• Butted tubing
• Tapered chainstays
• Integrated chain tensioners
• Adjustable 13,2 - 13,65 inch chainstay length
